Description

Product Specifications:

• Type: Automatic Voltage Regulator (AVR)
• Phase: Three Phase (Tri-Phase)
• Rated Capacity: 200,000 VA (200kva)
• Input Voltage Range: 290V – 500V
• Output Voltage: 400V AC (Auto/Manual selectable)
• Frequency: 60Hz
• Control Type: Digital Control Circuit Board
• Regulation Mechanism: Mechanical Servo Regulator
• Breaker: 630A Power-On Breaker with Shut Trip Relay
• Built-In: Main Dry Type Transformer
• By-Pass Function: Equipped with Manual By-Pass Switch
• Output Adjustment: Manual Voltage Fine-Tuning Control
• Protection Features: High/Low Voltage Protection, Overload & Short Circuit
• Startup Feature: Automatic Power-On Delay for safe system energization

Key Features & Attributes:

• High-Capacity AVR: Supports large-scale power applications with its 200kVA rating.
• Tri-Phase Stability: Designed for 3-phase, 400V applications—ensuring even voltage distribution and reduced imbalance.
• Wide Input Range: Efficiently stabilizes power across fluctuating inputs from 290V to 500V.
• Auto/Manual Output Control: Offers both automatic regulation and manual override for critical load management.
• Heavy-Duty Circuit Protection: With a 630A breaker and integrated digital controls for real-time monitoring and safety.

Performance & Application:

• Consistent Voltage Regulation: Protects sensitive industrial or commercial equipment from voltage spikes, sags, and irregular power.
• Industrial Grade Reliability: Ideal for factories, manufacturing plants, high-load electrical systems, and buildings with variable power demand.
• Long-Term Durability: Built with a robust transformer core and servo motor system designed for continuous operation in demanding environments.

Safety & Benefits:

• Surge & Overvoltage Protection: Safeguards equipment against power surges and voltage fluctuations.
• By-Pass Feature: Ensures uninterrupted power supply during maintenance or AVR failure by switching to bypass mode.
• Delayed Startup: Reduces risk of initial power surge damage upon power resumption.
• Digital Monitoring: Allows for accurate status tracking and error alerts.
• Energy Efficient: Reduces energy losses by maintaining optimal voltage levels.

Why Choose JVH AVR 400V with By-Pass – 200kVA?

• Provides industrial-grade voltage regulation with high stability and power protection.
• Perfect for mission-critical operations where voltage fluctuation can damage equipment or halt productivity.
• Equipped with advanced safety features and manual control options for flexibility and peace of mind.
• Offers seamless integration into three-phase systems operating at 400V.
