Description

KEY FEATURES

• Capacity: 80KVA
• Phase: Tri-Phase
• Input Voltage: 220V–460V
• Output Voltage: 380V AC (Auto/Manual)
• Frequency: 60Hz
• Control System: Servo Motor Regulation
• By-Pass Switch: Yes (for continuous operation during maintenance)
• Startup Delay: 5–8 seconds to protect sensitive loads
• Digital Display: For accurate voltage monitoring
• Main Protection: ELCB (Earth Leakage Circuit Breaker)
• Terminal Log: Secure connection for heavy-duty wiring
• Breaker Rating: 160AMP
• Safety Features: Overload, surge, and short-circuit protection

APPLICATIONS

The JVH AVR TNS-80KVA-J is designed for heavy-duty and sensitive applications, including:

• Industrial Plants: Large machinery, motor-driven equipment, and automation systems
• Commercial Buildings: HVAC systems, elevators, centralized electrical systems
• Data Centers: IT equipment, servers, and backup power systems
• Hospitals & Medical Facilities: Diagnostic and life-support machines
• Power Generation & Utilities: Voltage stabilization for essential equipment
• Construction & Mining: Heavy electrical loads and site power distribution

The JVH AVR TNS-80KVA-J is a high-capacity tri-phase Automatic Voltage Regulator engineered to provide stable and accurate voltage output for large industrial and commercial applications. With an 80KVA capacity and an input voltage range of 220V–460V, it ensures consistent power delivery at 380V AC (Auto/Manual) mode.
This model incorporates servo motor control for precise voltage regulation, a digital display for real-time monitoring, and an ELCB (Earth Leakage Circuit Breaker) for superior protection against electrical hazards.
A By-Pass switch enables uninterrupted power during maintenance or emergency scenarios, while the 5–8 second start-up delay safeguards connected equipment from sudden surges.

Additional information

Brand

JVH AVR
