Description

Specifications & Electrical Details:

• Model: TNS2-100KVA-J
• Phase: Tri-Phase
• Rated Capacity: 100KVA
• Input Voltage Range: 150V – 250V AC
• Output Voltage: 220V AC
• Frequency: 60Hz
• Terminal Type: Terminal Log
• Output Current Capacity: 250 Amps

Key Features & Attributes:

• Digital Display Meter
  Displays real-time input/output voltage, making monitoring fast and accurate.
• Automatic Power-On Delay
  Protects equipment from voltage surges during power restoration.
• Thermal Overload Relay
  Automatically cuts off power during overheating to prevent equipment damage.
• By-Pass Switch
  Enables manual operation during maintenance or AVR servicing.

Performance Highlights:

• High Precision Voltage Regulation
  Stabilizes voltage fluctuations to safeguard sensitive and high-value electrical equipment.
• Quick Response Time
  Delivers immediate correction for over/under voltage conditions.
• Consistent Output
  Maintains stable 220V even during extreme input voltage variations within range.

Applications:

Perfect for powering:

• Industrial and Commercial Electrical Systems
• Large-scale HVAC Units
• Elevators, Compressors, Pumps
• Laboratories, Hospitals, Data Centers
• Any facility using 3-phase 220V systems with fluctuating power sources

Safety & Operational Benefits:

• Extended Equipment Lifespan through clean and constant voltage output
• Minimal Downtime due to automatic restart and protection systems
• Reduced Risk of Damage from overloads and thermal surges
• Operational Flexibility with integrated bypass function
• Easy Troubleshooting & Monitoring via user-friendly digital interface

Why Choose JVH Tri Phase 220V (150V–260V) TNS2-100KVA-J?

The TNS2-100KVA-J model is engineered for reliability and efficiency in demanding tri-phase applications. It combines stable output performance, advanced protection features, and manual control options to ensure uninterrupted operation, especially in areas with unstable grid voltage. With its digital monitoring, thermal overload protection, and built-in bypass system, this AVR is a trusted power partner for industries requiring clean and stable 220V power delivery.
